SecureData SecureDrive KP
Hardware-Encrypted, External Portable Drive with Keypad

Overview

SecureDrive KP: Total Control of Your Data

Eliminate data leaks and protect digital files with the hardware-encrypted SecureDrive KP. The device is hardware-encrypted and is FIPS-validated. It is unlocked by entering the user PIN via the onboard keypad. The keypad is wear-resistant to prevent unauthorized parties from seeing commonly used keys.

If the SecureDrive KP is stolen, the brute-force, anti-hacking mechanism wipes the drive clean after 10 consecutive failed PIN entries. Epoxy coating on internal components prevents hackers from accessing data through physical tampering. The device is OS-independent and can be used across all devices with a USB port.

External hard drive with extra security features:

• FIPS 140-2 Level 3 Validated: Certificate #3297
• Award Winning: Red Dot 2019 Award Winner
• Works with any device with a powered USB port
• Hardware encryption: XTS-AES 256-bit
• Interior parts covered in epoxy to prevent media removal from hackers
• Alphanumeric keypad for user authentication (7 – 15-digit PIN)
• Brute-force, anti-hacking protection
• Safe delete/wipe of all data/keys
• Admin/user modes
• Read Only mode
• Auto-lock
• Preloaded with DriveSecurity ESET Antivirus (1-year license included)

Features

Specifications

Specifications
Capacity	250 GB – 8 TB
Size	SSD & 500 GB; 1, 2 TB HDD - H: 125 mm W: 77 mm L: 12.5mm 4 & 5 TB HDD - H: 125 mm W: 77 mm L: 20.5 mm
Weight	Approx. 255 g (340 g - 5TB HDD)
User Authentication	Ergonomically designed 10+1 keypad
Security Validation	FIPS 140-2 Level 3 validated
Encryption	Real-time, military-grade XTS-AES 256-bit full-disk hardware encryption
Data transfer speed	Reads up to 292 MB per second; writes up to 299 MB per second
Interface	USB 3.0/3.1 gen1/3.2 gen1
Physical Protection	Protected with epoxy compound to prevent physical access to the device through tampering.
Complete Drive Reset (Safe Erase)	Erases all data after 10 consecutive, incorrect PIN entry attempts
Immune to Bad USB	Yes; firmware updates not allowed
Roles/Permissions	1 Admin, 1 User
Read Only Mode	Yes
Inactivity Auto-lock	Predefined times between 1 and 60 minutes
OS Compatibility	Windows, MacOS, Linux, Chrome, Thin Clients, Embedded Systems, VMware, Citrix (no software or drivers needed)
Regulatory Approvals	RoHs, FCC, CE, FIPS 140-2 Level 3
Warranty	2-year limited (HDD) 3-year limited (SSD)

Video

SecureDrive KP Encrypted Hard Drive Demo

This video explains the functionality and showcases the features of the SecureDrive KP Encrypted Hard Drives.

Frequently Asked Questions

How do I unlock/lock the drive?

Press the Key button and enter your user PIN, followed by the Key button again. To lock, disconnect the drive or press and hold the Key button for 2 seconds.

Can I take the PIN off?

No. SecureDrive KP is a sophisticated, hardware-encrypted drive which must have a PIN to operate.

How quickly can I purge the data?

Press 7 + Key, then enter 999, then press 7 + Key. All user data and drive formatting will be immediately reset beyond recovery.

If I forget my user password, does anyone have a copy or can I reset it?

If the Admin password was set up, the drive can be unlocked with Admin PIN. If no Admin PIN exists or it is not available, then there are no backdoors or resets. After 10 consecutive, incorrect attempts the brute-force, anti-hacking mechanism wipes all user data and drive attributes.

Why should I set up Admin PIN?

The key advantage is that in case the user PIN is entered incorrectly 10 consecutive times, the anti-hacking mechanism wipes the user PIN attributes but leaves the user data intact so that no more attempts to unlock via User Mode can be complete, but an Admin PIN can unlock the drive without data loss.

Do Admin mode and User mode see different files?

No. Admin mode and User mode view identical contents. Admin mode can override User settings such as Read Only and Auto-lock.

If I reset my drive can SecureData get my files back?

No. Resetting the drive activates a crypto erase command which deletes and then regenerates the encryption key. Once the key is gone there is absolutely no way to get it back. Even though there will be encrypted data on the drive, there is no viable way to decrypt it.

If I lost my drive, can I reset it remotely to delete my data?

No. Since the KP drive does not use our Remote Management system, there is no way to reset it remotely. Rest assured if the drive is lost or stolen without the user PIN, after 10 consecutive, incorrect attempts the anti-hacking mechanism will be triggered and wipe out all user data. (Remote Management options are available on any BT drive).

Documentation

Download the SecureData SecureDrive KP Keypad Encrypted Hard Drive Datasheet (.PDF)
